Packing / Carton Packer
/ SFA-3137 |
Back |
|
|
Carton Packer
SFA-3137 |
Description：
S-20 20-25 Cartons per minute.
Features：
●
Designed
for stacking various types of carton, box and plastic basket.
●
Employs
man-machine interfacing English Screen, provideing display for
trouble causes, self-diagnosis and trouble positions.
●
Carton
stacking quantity and layers can be set on the control panel.
●
Touch-sensing screen provides memory capability for memorizing the
stacking programs for saving time of change.
●
All
moving parts are equipped with grease nipples for convenient lubrication
and maintenance.
●
Low Bed
construction allows for convenient repairing and shooting trouble.
●
Applicable Products:Well packed products in carton, box and plastic basket. |
|
|
|
SPECIFICATION |
|
Model |
SFA-3137 |
|
Power Source |
220V-440V / 50HZ-60HZ |
|
Power Capacity |
8 KW |
|
Air Pressurre |
5-6.0 kg/cm2 |
|
Air Flow Consumption |
200L/min |
|
Machine Dimensions |
L6125mm X W5139mm X H2995mm |
|
Machine Weight |
3200kg |
|
Processing Capacity |
20-25 cartons /min |
|
Operation Control |
English screen display system |
|
Suitable Processing Package |
Plastic Plate, Wooden Plate and Paper Pallet |
|
|
|
